Home / All / Bathtub Components Wholesale / Whirlpool System / Water Pumps / Bathtub Water Pump WAH/WBH/WCH Series Wholesale | Long Lifespan and High Performance Pumps for Water Recirculation | Bulk Supply from Manufacturer
Bathtub Water Pump WAH/WBH/WCH Series Wholesale | Long Lifespan and High Performance Pumps for Water Recirculation | Bulk Supply from Manufacturer
0.25KW/0.33HP~1.1KW/1.5HP
260~490 QMAX(L/MIN)
260~490 QMAX(L/MIN)
| Categories | Water Pumps |
|---|---|
| Trademark/Brand | Hydrorelax Bathroom industry manufacturer |
| Model | WCH50, WCH75, WCH100, WCH150, WBH75, WBH100, WBH150, WBH200, WAH100, WAH150, WAH200 |
| Thermal protector: | with thermal protector( single phase motor) |
| Insulation rating: | F |
| Medium temperature: | 5~50℃ |
| Ambient temperature: | ≤50℃ |
| Maximum working pressure: | 0.3MPa |
| Certification: | UL Recognised Parts |
| Update Time | Nov 6,2025 |
Detail Information
Attention: P1 is the input power and P2 is the output power. Please confirm whether the power of the pump matches before purchasing.
Bathtub Water Pump Parameter
Bathtub Water Pump Performance Curves
Bathtub Water Pump Dimension
Bathtub Water Pump Exploded View
NO. | NAME | |||
1 | Tie-in Nut | |||
2 | Tie | |||
3 | O-Ring | |||
4 | Cross Raised Head Screw Assembling | |||
5 | Plain Washer | |||
6 | Pump Cover | |||
7 | O-Ring | |||
8 | Impeller | |||
9 | Mechanical seal | |||
10 | Pump Casing | |||
11 | O-Ring | |||
12 | Bracket | |||
13 | Motor | |||
Bathtub Water Pump Applications
